The primary land use is residential, as indicated by 'Proposed Residential Development.' The layout incorporates significant open green spaces, specifically two large central courtyards surrounded by residential blocks C and B. These green areas, complemented by tree-lined internal roads, form a core part of the community's design.

• The development features clear internal road networks, providing circulation throughout the residential blocks.
• There are two main 'ENTRY' points visible, one leading from the 24-meter wide proposed road and another from the 30-meter wide proposed road, indicating multiple access points for convenience.
• 'OUT' points are also indicated for egress.
• The property connects to key external thoroughfares: Golf Course Road (3.4 km), Golf Course Extension Road (0.75 km), and Sohna Road (4.2 km).

• A dedicated swimming 'POOL' is integrated within the northern cluster of Block A, offering recreational facilities.
• The plan features multiple central green areas or courtyards, providing residents with landscaped spaces.
• A 'SUB-STN' (Sub-station) is shown, providing essential utility infrastructure to the development.

• The development is bordered by a '24 METER WIDE ROAD (Proposed)' on one side and a '30 METER WIDE ROAD (Proposed)' on another, ensuring good external connectivity.
• The plan explicitly notes 'NOT TO SCALE,' indicating that dimensions should be taken as relative for planning purposes.
• A ramp for vehicular access or exit is marked as 'RAMP OUT' in the Block C area.
